Dimensions W x L x H: 692 x 580 x 680 mm
Mains supply voltage: 230 V
Power output: 2300 W
Top heating: 700W
Heating plate: large 1600 W (260 x 260 mm); small 400 W (120 x 120 mm)
Compressed air supply: 400 - 600 kPa clean, oil-free compressed air
Temperature control: continuously variable 50 °C - 400 °C
Temperatureaccuracy: ± 10°C (± 18°F)
Air volume hot air: continuously variable 5 - 50 l/min
Air consumption: 60 - 100 l / min
Safety class: 1
Order Information: Thermoelement Type K, Ø 0, 1 mm, NQ-Adapter, Vacuum insert Ø 10 mm, Vacuum insert Ø 4, 5 mm
Option:
ACCESSORIES
T0058754924 FIXTURE SET F. BOARDS WQB 3000
T0058755745 SUPPORT FOR WQB 3000 / WBH / WBHS
T0058766729 SUPPORT FOR ALLOY ANGLE WQB
T0058766725 DOWN HOLDER WQB 4000 F. PCB HOLDER AL
T0058766726 SET 2 ANGLES F. PCB-HOLDER WQB 4000
T0058754948 SENSOR PT100 FOR WQB 3000/ WQB 4000SOPS
T0058755782 THERMOCOUPLE TYPE K 0,1MM W. PLUG
T0053119099 TEMPERATURE SENSOR FOR WCB2
HOT AIR NOZZLE
T0058747947 HOTGAS NOZZLE 7.6X7.9 WQB
T0058747943 HOTGAS NOZZLE 6.5X6.5 WQB
T0058747945 HOTGAS NOZZLE 8.5X8.5 WQB
T0058747961 HOTGAS NOZZLE 8.5X10.6 WQB
T0058754967 HOTGAS NOZZLE 10X10 WQB
T0058747848 HOTGAS NOZZLE 12X12 WQB
T0058747904 HOTGAS NOZZLE 13.5X13.5 WQB
T0058747935 HOTGAS NOZZLE 15,5X15,5 WQB
T0058747893 HOTGAS NOZZLE 15X11 WQB
T0058754836 HOTGAS NOZZLE 18.5X10.0 WQB
T0058747977 HOTGAS NOZZLE 15.5X23.5 WQB
T0058747833 HOTGAS NOZZLE 18X18 WQB
T0058754770 HOTGAS NOZZLE 21X21 WQB
T0058754820 HOTGAS NOZZLE 22X22 WQB
T0058747764 HOTGAS NOZZLE 25X25 WQB
T0058747993 HOTGAS NOZZLE 27.0X23.0 WQB
T0058747850 HOTGAS NOZZLE 27X27 WQB
T0058747927 HOTGAS NOZZLE 29X29 WQB
T0058747999 HOTGAS NOZZLE 28,2X32,0 WQB
T0058747906 HOTGAS NOZZLE 33X33 WQB
T0058754887 HOTGAS NOZZLE 35X35 WQB
T0058747753 HOTGAS NOZZLE 37X37 WQB
T0058747871 HOTGAS NOZZLE 39,5X39,5 WQB
T0058747874 HOTGAS NOZZLE 42X42 WQB
T0058754903 HOTGAS NOZZLE 45X11 WQB
T0058747763 HOTGAS NOZZLE 46X46 WQB
T0058747916 HOTGAS NOZZLE 47X47 WQB
T0058747941 HOTGAS NOZZLE 49X49 WQB
T0058747985 HOTGAS NOZZLE 57X18.5 WQB
