Frequency range: 0.06 MHz to 35 MHz
Display: 320×240 color TFT display
Operating time (continuous measurements): Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used
Operating modes
SWR at single frequency
SWR, return loss, R, X, |Z|, L, C and phase angle at single frequency
SWR chart, 100 points
R, X chart, 100 points
RL chart, 100 points
Non Volatile memory: 10 slots to save measurement results
Built in Helper: Yes, at the push of a button
Localizations: English, Ukrainian, French, Japanese
Output connector: UHF (SO-239)
Output power: +13 dBm (at 50 Ohm load)
Battery
Two 1.5V alkaline batteries, type AA
Two 1.2V Ni-MH batteries, type AA
Operating temperature: 0°-40°C (32°-104°F)
PC/Mobile Interfaces: USB connection to a personal computer,
Bluetooth ver. 4.2 (Single-mode, Class B)
Dimensions: 103 x 207 x 37 mm (4.1 x 8.1 x 1.4 inches)
Weight (with battery installed): 310 grams (10.9 Oz) w/o batteries
