INSIZE LDM-090 ໄມໂຄມິເຕີສະແກນເລເຊີ (1-85mm)

SPECIFICATION

Measuring range: 1-85mm

Resolution: 0.01/0.1/1/10/100μm selectable

Accuracy (25°C in laboratory): ±6μm

Repeatability (25°C in laboratory): 3μm

Laser wave length: 650nm

Measuring speed: 800-3200 times/s (adjustable)

Operation temperature: 0~50°C

Operation humidity: 35-85RH without condensation

Output: dual channel RS485

Alarm output: 24V, 1A

Power supply : DC24V, 2A

Dimension (LxWxH): 608X60X162mm

Weight: 10kg

Standard delivery

Main unit: 1pc

V-block: 1pc

AC/DC adapter: 1pc

RS485 cable: 1pc

■Measure outer diameter, ellipticity, run-out,

maximum diameter of tools, etc.

■ Can be used for transparent or non transparent workpieces

■Tolerance measurement

■ Online or offline measurement

■ Connected with computer, PLC, control box
