Measurement Channels:
Voltage: 4 differential channels
Current: 4 channels
Voltage Measurement:
Range: 0 – 1000 Vrms, AC/DC
Accuracy: ±0.1% of reading
Transients: up to 1414 Vpk
High-speed transients: up to 2000 Vpk
Current Measurement:
Range: Probe dependent, AC/DC
Accuracy: ±0.1% of reading ±0.05% FS
Frequency Measurement:
Range: 16 – 25 Hz / 42.5 – 69 Hz
Accuracy: ±0.01 Hz
Sampling & Resolution:
512 samples/cycle
16-bit resolution
Power & Energy Parameters:
Active, reactive, apparent power
Power factor (true & displacement)
Demand and energy measurement
Display: 7" WVGA color touchscreen LCD
Memory: Internal memory: 4 GB
Interfaces & Communication:
Ethernet
USB (OTG)
Optional Bluetooth
VNC remote access
Mobile apps (Android & iOS)
Power Supply: AC adapter: 100–240 V AC, 50/60 Hz
Internal rechargeable battery: approx. 3 hours runtime
Safety Category:
Voltage inputs: CAT III 1000 V
Mains supply: CAT II
Operating Temperature: 0°C ~ +50°C
Storage Temperature: –20°C ~ +55°C
Humidity: 10 – 90% RH, non-condensing
Max. Altitude: 2000 m
Dimensions (W × H × D): 254 × 203 × 70 mm
Weight: approx. 1.9 – 2.0 kg
