Temperature Range: 0-150°C (300°F)
Pressure Range: 0-20,000psi (150Mpa)
Output Signal: PT100
Electrical Cable Indicators: Red: Power +
Black: Signal +
Accuracy: 0.5%
Connection: 1/4″ HP coupling (9/16″UNF-18-Male); 3/8″ HP coupling (3/4″UNF-16-Male)
Standard Features:
Materials: Sanitary 316 stainless steel
Compatibility: Homogenizers of all brands
Other Features: Long-term stability; high accuracy
Material Standard: Compliance with FDA and GMP sanitary standards
Description:
Genizer electronic temperature transmitter is designed for recording the temperature with output signal PT100. GTT-150Mpa is a precision temperature transmitter suited for measuring temperatures up to 150°C (300°F) and ideal for high pressure applications.
Application:
≤ 20,000 psi high pressure homogenizer or other high pressure devices.
Performance:
Sanitary for pharmaceutical applications
Long-term stability
High accuracy
Datasheet
