EXTECH IRC130 Thermal Imager ເຄື່ອງວັດແທກອຸນຫະພູມ IR (-25 ~ 650°C; 80 x 60 (4800 pixel); < 70 mK)
Specifications
Temperature range: -13 to 1202°F (-25 to 650°C)
Basic accuracy: ±1% of reading or ±1°C (2°F), whichever is greater
Image storage capacity: 50,000 JPEG images (with spot temperature metadata tag)
Emissivity: 0.10 to 0.99 (adjustable) and 3 presets
Response time: 150 ms
Imaging and Optical Specifications
IR Resolution: 80 x 60 (4800 pixels)
Digital Camera Resolution: 2 MP (megapixels)
Thermal Sensitivity /NETD: < 70 mK
Field of View (FOV): 51° x 66 (H x W)°
Minimum focus distance: 0.3 m (0.89 ft.)
Distance to Target: 30:1
Dual range operation : Range 1: < 752°F (400°C); Range 2: > 752°F (400°C) - For Range 2, the high temperature lever must be engaged
Focus: Fixed
Image frequency: 8.7 Hz
Focal plane array/Spectral response range: Uncooled microbolometer/7.5 ~ 14 μm
Image Presentation Specifications
Display resolution: 320 x 240 pixels
Screen size: 2.4" (61 mm) - portrait
Viewing angle: 80°
Display type: TFT technology
Image modes: Visual and Visual/Thermal MSX (Multi-Spectral Dynamic) images
Color display palettes: Iron, Rainbow, White-hot, Black-hot, Arctic, and Lava
Image gallery: Yes
Additional Information
IP rating: IP54 (IEC 60529)
Drop tested: ~6.5 ft (2 m)
Accessory mount: UNC 1/4"-20
Power: Internal rechargeable battery (3.6 V Lithium Ion)
Dimensions/Weight: 8.3 x 2.5 x 3.2" (210 x 64 x 81 mm)/13.9 oz (394 g)
