Max. Power: 2000 VA
Max. Voltage: AC (rms) 150 V / 300 V
DC ± 212 V / ± 424 V
Max. Current (rms): 0 - 150 V: 20 A
0 - 300 V: 10 A
Frequency Range: Single phase: 45 Hz~1200 Hz
3-Phase: 45 Hz~600 Hz
Total Harmonic Distortion (THD): ≤ 0.5 % tại 45 Hz~400 Hz (resistive load)
Remote Interface: LAN, USB, GPIB, and RS232
Programming Resolution:
Voltage: 0.1 V
Phase: 0.1 º
Frequency: 0.01 Hz (< 100 Hz), 0.1 Hz (> 100 Hz)
Measurement Resolution:
Voltage: 0.1 V
Current: 0.01 A
Power: 0.01 W
Frequency: 0.01 Hz (< 100 Hz); 0.1 Hz (> 100 Hz)
AC Input:
Voltage: 190 V~250 V
Frequency: 47 Hz~63 Hz
Maximum Power: 3800 VA
Maximum Current: 20 A
Power Factor: 0.98 (typical)
General:
Analog BNC Input:
Input Voltage Range: 0~± 10 V
Input Impedance: 200 kΩ
Bandwidth: 1.2 kHz
Protection: OVP, OCP, OPP, OTP
Operating Temperature: 32~104°F (0~40°C)
Storage Temperature: -40~185°F (-40~85°C)
Environmental Conditions: ≤ 80% Relative Humidity up to 35 ºC, non-condensing
Dimensions (W x H x D): 16.5” x 5.2” x 22” (420 x 132 x 560 mm)
Weight: 52.9 lbs (24 kg)
Included Accessories: AC power cord with input connector, test report & certificate of calibration
Optional Accessories Rackmount ears with handles (RK3U) & 3-Phase sync adapter (TL983P), 3-Phase kit (TL983P-KIT)
