Output Rating
Voltage: 32 V
Current: 8 A
Maximum Output Power: 120 W
Load Regulation ± (% output + offset)
Voltage: ≤ 0.01% + 3 mV
Current: ≤ 0.01% + 3 mA
Line Regulation ± (% output + offset)
Voltage: ≤ 0.01% + 2 mV
Current: ≤ 0.01% + 3 mA
Ripple and Noise ( 20 Hz to 20 MHz )
Normal Mode Voltage p-p: ≤ 5 mV
Normal Mode Voltage rms: ≤ 1 mV
Normal Mode Current rms: ≤ 3 mA
Programming / Readback Resolution
Voltage: 1 mV
Current: 1 mA
Programming / Readback Accuracy ± (% output + offset)
Voltage: 0.03% + 4 mV
Current: 0.1% + 5 mA
Temperature Coefficient per °C
Voltage: 6.4 mV /°C
Current: 1.6 mA /°C
Output Response Time
Rise Time
Full load: 10 ms
No load: 10 ms
Fall Time
Full load: 10 ms
No load: 250 ms
Transient Response
Time: 0.5 ms
Protection
OVP: Range: 35.2V, Accuracy: 320 mV
OCP: Range: 8.8 A, Accuracy: 80 mA
Accessories
Standard Accessories: Power Cord & Certificate of Calibration
Optional Accessories: RK2US Rack Mount Kit
