DC Voltage range, resolution: 100mV~1000V, 1 µV~10 mV
DC Current range, resolution: 100µA~10A, 1 nA~100 µA
DC Resistance range, resolution: 10 Ω~100 MΩ, 0.1 mΩ~1 kΩ
Capacitance range: 1 nF~10mF
True RMS AC Voltage: 100 mV, 1 V, 10 V, 100 V, and 750 V
True RMS AC Current: 100 µA~10 A
Continuity range: 1 kΩ; Test current: 1 mA
Diode: 5V; Test current: 1 mA
General:
AC Input: 110 V/220 V ±10%, 50/60 Hz
Power Consumption: ≤ 30 VA
I/O Interface: RS232, USB host, USB (USBTMC-compliant) device, LAN, GPIB (5492CGPIB and 5493CGPIB only)
Temperature Operating: 32 °F to 104 °F (0 °C to 40 °C)
Storage: -40 ºF to 158 ºF (-40 ºC to 70 ºC)
Humidity: Indoor use, ≤ 95 %
Safety: EN 6110-1:2010, Low Voltage Directive (LVD) 2014/35/EU
Electromagnetic Compatibility: EN 61326-1:2013, EMC directive 2014/30/EU
Dimensions (W x H x D): 8.85” x 3.93” x 13.97” (225 mm x 100 mm x 355 mm)
Weight: 5.51 lbs (2.5 kg)
Standard Accessories: Power cord, USB cable, test leads, spare fuses, test report and certificate of calibration
Optional Accessories: Rack mount kit (RK02), high performance bench DMM accessory kit (TL500B), general purpose DMM kit (TL130B), Maxi-Pro DMM kit (TL50B), replacement probes (TL37)
