BK Precision 4086AWG Arbitrary Waveform / Function Generators (80Mhz, 1CH)
Manufaturer: BK Precision - USA
Model: 4086AWG
Channels: 1
Sine: 1µHz ~ 80MHz
Square: 1µHz ~ 40MHz
Triangle, Ramp: 1µHz ~ 100kHz
Built-in Waveforms: Sine, Square, Triangle, Positive Ramp, Falling Ramp, Noise, Pulse, Positive Pulse, Negative Pulse, Positive
DC, Negative DC, Stair wave, Coded Pulse, Full wave rectified, Half-wave rectified, Sine transverse cut, Sine vertical cut, Sine phase modulation, Logarithmic, Exponential, Half-round, Sinx/x, Square root, Tangent,
Cardiac, Earthquake, Combination
Amplitude Range: 1mV ~ 10Vpp (50Ω)
Modulation: AM, FM, FSK, PSK
Universal Counter: 1Hz ~ 100MHz
Remote Interface: RS-232
Dimensions: 255 mm x 100 mm x 370 mm
Weight: 3 kg
Power: 198~242V or 99~121V ,
Include: BNC to alligator cable, BNC to BNC cable, RS232 communication cable, power line cord, test report, spare fuse, software installation disk.
