Maximum Frequency: 30 MHz
Waveforms:
Standard: Sine, Square, Triangle/Ramp, Pulse
Built-in Arbitrary: Sine, Triangle, Square, Noise, Ramp Up, Ramp Down, Sine(X)/X, Exponential Up, Exponential Down, Gaussian, Lorentz, Haversine
User-defined Arbitrary: 4 Mpts
Operating Modes
Operating Modes: Continuous, Triggered, Burst, Gated, Phase
Triggered: Frequency of waveform cycle is limited to 10 MHz
Sine
Frequency Range: 1 mHz to 30 MHz
Resolution: 1 μHz
Square
Frequency Range: 1 mHz to 30 MHz
Rise & Fall Time: < 5 ns (10% to 90%) at full amplitude into 50 Ω
Overshoot (typical): < 2%
Variable Duty Cycle Range
fout ≥ 10 MHz : Set duty = 50 %
fout ≥ 100 kHz: Set duty 20% to 80%
fout < 100 kHz: Set duty 5% to 95%
Duty Cycle Resolution: 0.1%
Duty Cycle Accuracy: < ± 0.1% ± 5 ns
Jitter (rms): < 40 ps rms
Ramp & Triangle
Frequency Range: 1 mHz to 5 MHz
Resolution: 1 μHz
Variable Duty Cycle
0%-100% to 500 kHz
20%-80% to 2 MHz
Fixed 50% to 5 MHz
Duty Cycle Resolution: 0.1%
Linearity: < 0.1% of signal amplitude from 5%-95%, up to 200 kHz
Pulse
Frequency Range: 1 mHz to 10 MHz
Resolution: 1 μHz
Pulse Width: 20 ns minimum, 1 ns resolution, 999 s max
Variable Edge Time: < 10 ns to pulse period (depending on pulse width)
Jitter (rms): < 25 ps
Arbitrary Waveform Characteristics
Waveform Length: 2 pts to 4,194,305 pts
Sampling Rate: 250 MSa/s, point execution rate adjustable from
4 ns to 100 s
Voltage Resolution: 16 bits (65,536 levels)
Noise: Programmable 1% to 100% or added to arbitrary waveform
Bandwidth: 50 MHz max (2-point waveform length)
Frequency
Accuracy: ± 10 ppm
Rate Resolution: 10 ps, up to 8 digits
Rise & Fall Time: 6 ns minimum
Jitter (rms): < 40 ps (rms)
Sweep Characteristics
Sweep Shape: Linear and Logarithmic, up or down
Sweep Time: 10 ms to 100 s
Sweep Trigger Mode: Internal, External, Continuous, or Burst
