BK Precision 4052 Dual Channel Function/Arbitrary Waveform Generators (5Mhz, 2CH)
Channels: 2
Sine: 1 µHz – 5 MHz
Square: 1 µHz – 5 MHz
Triangle, Ramp: 1 µHz – 300 kHz
Pulse: 500 µHz – 5 MHz
Built-in Waveforms: 48 built-in waveforms (includes DC)
Amplitude Range: CH1: 2 mVpp – 10 Vpp into 50 Ω, CH2:2 mVpp – 5 Vpp into 50 Ω
Pulse Width: 16 ns minimum, 8 ns resolution
Burst: sine, square, ramp, pulse, arbitrary (except DC)
Phase Offset: 0 ° – 360 °
Trigger: TTL compatible
Modulation: AM, FM & PM, ASK & FSK, DSB-AM, PWM
Frequency Counter: 100 mHz – 200 MHz
Display: 3.5” TFT-LCD display, 320 x 240
Power: 100-240VAC
Dimensions: 213 x 89 x 281 mm
Weight: 2.6 kg
Standard Accessories: Getting Started manual, full instruction manual on CD, AC power cord, USB type A-to-type B cable, certificate of calibration
