Bandwidth:100 MHz
Input Channels 4 Analog Channels
Sample Rate 2 GSa/s (single channel)
Typical Rise Time < 3.5 ns (
Memory Depth 140 Mpts (single channel),
Waveform Update Rate 140,000 wfms/s
Input Coupling DC, AC, GND
Input Impedance 1 MΩ ± 2% || (22 pF ±3 pF)
50 Ω ± 2%
Vertical Resolution 8 bits
Vertical Sensitivity 500 μV/div to 10 V/div (1-2-5 )
Maximum Input Voltage 1 MΩ: < 400 Vpk; 50 Ω: < 5 Vrms
DC Gain Accuracy ±3%: 5 mV/div to 10 V/div; ±4%: < 2 mV/div
Modes Auto, Normal, Single
Coupling DC, AC, LF Reject, HF Reject,
Noise Reject Ch1-Ch4
Trigger Level
Internal: ±4.5 div from center
External: EXT: ±0.6 V
EXT/5: ±3 V
Hold-Off Range 100 ns to 1.5 s
Types Edge, Slope, Pulse, Video, Window,
Interval, Dropout, Runt, Pattern
Serial Trigger I2C, SPI, UART/RS232, CAN, LIN
Waveform Measurements
Voltage
Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Mean,
Cmean, Stdev, Cstd, Vrms, Crms, FOV, FPRE, ROV,
RPRE, Level@Trigger
Time +SR, -SR, Period, Freq, +Width, -Width, Rise, Fall,
BWidth, +Duty, -Duty, Time@Mid
Delay Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFF, Skew
Statistics Current, Mean, Min, Max, Stdev, Count
Gating Time domain
I/O Interface
Standard USB Host, USB Device, LAN, Pass/Fail, Trigger Out
Pass/Fail 3.3 V TTL Output
Display 8” Color TFT-LCD, 800 x 480 Resolution
Wave Display Mode Vectors, Dots
Persistence Off, Infinite, 1 sec, 5 sec, 10 sec, 30 sec
Intensity Grading 256 Levels
Language
English, French, Japanese, Korean, German,
Russian, Italian, Portuguese, Simplified Chinese,
Traditional Chinese
Power Requirements 100 to 240 VAC, CAT II, 50 VA Max,
45 Hz to 440 Hz
Dimensions (W x H x D) 13.8” x 5” x 8.8” (352 x 128 x 224 mm)
Weight (4-ch) 7.9 lbs (3.6 kg)
(2-ch) 7.5 lbs (3.4 kg)
included Accessories
Passive probes (one per channel), power cord,
certificate of calibration,
USB (Type A to B) communication cable
Optional Accessories 16-channel digital logic probe (LP2560)
