MAIN OUTPUT:
Output Voltage Adjustable Range: 1.0 – 36 VDC
Output Current Adjustable Range: 0 – 3 A
Voltage Regulation:
Load (10 % to 100 %): ±50 mV
Line (min to max): ±20 mV
Ripple: ±5 mV rms
Noise (Peak to Peak): ±50 mV
Current Regulation:
Load (10 % to 100 %): ±20 mA
Line (min to max): ±20 mA
USB OUTPUT:
Output Voltage: 5 V (±10 %)
Output Current: 400 mA (±10 %)
Load Voltage Regulation: 80 mV (±10 %)
Ripple & Noise (no load rms): 8 mV (±10 %)
OTHER:
AC Input: 230 VAC
Efficiency at Max Power: 83 % (±10 %)
Voltmeter and Ammeter Display: 3 Digit
Voltmeter Accuracy: ±1 % of rdg. ± 5 digits
Switching Operation Frequency: 80 kHz to 120 kHz
Ammeter Accuracy: ±1 % of rdg. ± 5 digits
LCD Indication: CC, CV, Amp, Volt, Output ON-OFF
GENERAL:
Protection: Short Circuit, Overload, Over Temperature, Over Voltage
Dimensions (W x H x D): 2.8” x 6.0” x 9.8” (70 x 150 x 250 mm)
Weight: 4.4 Lbs. (2 kgs)
