Input Power
- Line Voltage: 400 VAC ±10%; 3 φ, 4 wire, 50 ~ 60 Hz, no neutral
- Line Current: 5 A per φ, nominal line
- Line Regulation: ±1% for a 10% line voltage change or a ±2% frequency change
- Overcurrent Protection: 10 ADC bus fuse
Output:
- Output Power: 3kW
- Output Voltage: 370 ~ 1000 VDC full-power output
- Output Ripple Voltage: Component of output ripple voltage related to input line
frequency: ±5% RMS
- Efficiency: > 90% at full power
- Power Factor: 0.87 for loads > 0.3 kW; 0.9 for loads > 2.4 kW
- Repeatability: From run to run at a constant set point:
0.1% from 15 ~ 100%-rated power
0.2% at < 15%-rated power
- Load Regulation: ±1% for 4:1 load change within V-I limits of tap range
- Temperature Coefficient:
< 0.005% per 1ºC variation in the regulated output parameter over +20 ~ +40ºC (+68 ~ +104ºF) ambient temperature range from 20 to 100% of full scale
- Size: 87 mm (H) x 216 mm (W) x 517 mm (D); 3.4" (H) x 8.5" (W) x 20.4" (D)
- Weight: 9.1 kg (20 lb)
