ZuoYeal ZY-CSF200 ເຄື່ອງມວນອຸດສາຫະກຳອຸດສາຫະກຳ Ultrasonic Flowmeter ປະເພດຕໍ່ກັນ (0 ~ 40 m/s)

Measurement principle : Ultrasonic time difference

Measurement range : （0 ~ 40）m/s

Measurement accuracy : ≤1.0 %

Resolution : 0.1m/s

Output Limit : ≤0.1m/s

Repeatability:  ±0.1m/s

Zero drift : ≤±0.1m/s

response time : 5s (Adjustable)

Measuring medium : Flue gas,coal gas

Working medium temperature range : -40 ~ 450℃

Work pressure : -6.1Kpa ~ 10.0Kpa

Ambient temperature : -40 ~ 60℃

Probe Material : 304/316L stainless steel

Installation method : Split type/Opposite type

Power supply : 220VAC

Weight : 18 kg

IP level : IP65
