Operating system: Windows 10/8.1/7/Vista/XP/2000
Interface: USB 2.0
Sample rate (Internal Clock): 100 Hz ~ 200 MHz
Sample rate (External Clock): 75 MHz
Bandwidth: 75 MHz
Working voltage range: -6 V ~ +6 V
Accuracy: ±0.1 V
Memory: 1 Mbits
Depth per channel: 64 Kbits
Data compression: up to 256x
Trigger condition: Pattern / Edge
Trigger channels: 16 CH
Trigger delay: Yes
Trigger level: 1 level
Trigger count: 1 ~ 65535
Time base range: 5 ps ~ 10 ms
Vertical size: 1 ~ 5
Language: Chinese / English
Max trigger pages: 8192 pages
Data contrast: Not supported
Latch function: Not supported
Protocol packet trigger: Parallel
Power supply: USB (DC 5V, 500 mA)
Power at rest: 1 W
Power consumption: 2 W
Maximum input voltage: ±30 V
Impedance: 500 kΩ // 10 pF
Certifications: FCC / CE / WEEE / RoHS / REACH
Dimensions: 125 × 92 × 25 mm
Test cable: 8 pin ×2, 2 pin ×1, 1 pin ×1
Probe: 20 pcs/package
USB cable: 1
Driver CD: 1
Installation guide: 1
Carry bag: 1
