Zebra FS10 ຕູ້ສະແກນອຸດສາຫະກຳຕັ້ງຖືກ (1D; 2D; OCR; 1.0 MP)

Dimensions (H x D x W): 25.4 mm x 51.0 mm x 43.0 mm

Weight: 4.23 oz / 120.0 g

Power Supply: 5 VDC, 1 A max (5 W)

Color and Material: Industrial blue aluminum housing

Interface: 1 USB 2.0 High-Speed Type-C connector

Indicators: Decode/Job Status LED, Power LED, Online/Run LED, Beeper (adjustable volume)

Image Sensor: 1.0 MP (1280 × 800 pixels) CMOS sensor with global shutter and 3.0 μm pixel size

Acquisition Rate: Up to 60 frames per second

Aimer: Amber LED; circular pattern

Illumination: One 660 nm Red LED and one 2700 K White LED

Imager Field of View: 6.0 mm Liquid Lens: 35° H × 26° V (Nominal)

Operating Temperature: 32°F to 113°F / 0°C to 45°C

Storage Temperature: -40°F to 158°F / -40°C to 70°C

Humidity: 5% to 90% RH, non-condensing

Protection Rating: IP65 and IP67

1D Barcode Reading: Codabar, Code 39, Code 93, Code 128, Interleaved 2 of 5, MSI Plessey, UPC/EAN

2D Barcode Reading: Aztec, Data Matrix, DotCode, MaxiCode, PDF417, Micro PDF417, QR Code, Micro QR

OCR Barcode Reading: Deep Learning-based OCR via optional license add-on. Supports Latin characters (A–Z, a–z, digits, or one of the following: !#$%&()*+,-./:;<=>?@[]^_`{|}~)

Management Software: Zebra Aurora
