Circulation Type: External closed circulation
Circulating Water: Tap water, glycol (liquid temperature below 10°C)
Operating Temperature Range: 5℃ ~ 35℃
Temperature Control Range: −20°C to +30°C
Temperature Adjustment Accuracy: JTM K05 ±1°C
Temperature Fluctuation: JIS 3.0°C
Cooling Capacity: Approx. 1230 W at 10°C liquid temp / Approx. 560 W at −10°C liquid temp
Maximum Flow Rate (50/60 Hz): Approx. 12 / 14 L/min
Maximum Lift (50/60 Hz): Approx. 10.3 / 14.3 m
Temperature Control Method: Refrigerator ON / OFF control
Controller: White LED digital display, key input, minimum digit 1°C
Refrigeration System / Capacity / Refrigerant: Air-cooling / 650 W / R407C
External Circulation Nozzle: One-touch connector (Flexible rotary L type)
Water Circulating Pump: Magnet pump 65 W / 65 W
Flow Control: Flow control valve (Discharge port)
Safety Features:
Electric leakage breaker
Temperature sensor abnormality
Temperature upper/lower limit alarm
Compressor overload relay
Fan motor protection
Pump thermal protector
Refrigerator high-pressure switch (CF802)
Drainage hose
Circulation pump switch
Calibration offset
Power outlet 2A (CF802)
Bath Material: Stainless steel
Inner Tank Capacity (Liquid Volume): Approx. 15.5 L (liquid volume 14 L)
External Dimensions (W×D×H): W340 × D370 × H838 mm
Weight: Approx. 43 kg
Power Source (50/60 Hz) / Rated Current: AC220 V ±10% / 15 A (15 A plug)
Accessories:
Hose nozzles (for soft hose connection) × 2 pcs
Dew condensation water drainage hose (I.D. φ12 mm, 1 m length) × 1
Hose clamps × 2 pcs
