Width: 9.80 mm
Height: 2.30 mm
Length: 11.68 mm
Fall Time: 180 ns
Rise Time: 110 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Singe
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 265 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 3.75 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 56 ns
Typical Turn-Off Delay Time: 90 ns
Id - Continuous Drain Current: 400 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 200 S
Rds On - Drain-Source Resistance: 1.2 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 5 V
