Transmitter specifications:
Output mode: direct connection output, induction, caliper coupling.
Output frequency: 348Hz, 624Hz, 1280Hz, 1860Hz, 512Hz, 645Hz, 820Hz, 940Hz, 6KHz, 8kHz, 9kHz, 12KHz, 33kHz, 82kHz, 200kHz.
Output power: maximum 10W, adjustable in 10 levels, automatic real-time impedance matching.
Direct connection output voltage: up to 200Vpp.
Overload and short circuit protection.
Human-machine interface: 320×240 dot matrix liquid crystal display.
Built-in battery: 6 18650 lithium ion batteries, nominal 12.6V, 4.2Ah.
Receiver specifications:
Input mode: built-in receiving coil, identification clamp (optional), fault checking A-frame (optional).
Receiving frequency:
Detection frequency: 348Hz, 624Hz, 1280Hz, 1860Hz, 512Hz, 645Hz, 820Hz, 940Hz, 6KHz, 8kHz, 9kHz, 33kHz, 65kHz, 82kHz, 131kHz, 200kHz.
Power frequency passive detection frequency: 50Hz/60Hz.
Pipeline detection mode: broad peak method, narrow peak method, sound valley method, peak valley method.
Cable identification mode: caliper (optional) intelligent identification and current measurement.
Human-machine interface: 480×272 dot matrix liquid crystal display.
Built-in battery: 4 18650 lithium-ion batteries, nominal 4.2V, 8.2Ah.
Positioning accuracy: depth 0-3m (±5%), depth 3-12m (±10%)
Depth measurement accuracy: three digits display, the maximum depth can be measured up to 12 meters
Current measurement accuracy: 1Ma
Maximum detection distance: The cable with good insulation in the direct Connection Method can reach Up To 15KM
Other
Volume: transmitter 320×240×90mm, receiver 670×128×310mm.
Quality: 1.9kg for transmitter and 1.4kg for receiver.
Charger: input AC100~240V, 50/60Hz, output DC4.2V-1A, output DC12.6V-1A.
Operating conditions: temperature: -10ºC-40ºC, humidity 5-90%RH, altitude <4500m.
