XP Power HRL3024S1K0N ບໍ່ແຍກສ່ວນ / PoL 30W 0 ຫາ -1000V 1.5A

Width: 50.8 mm (2 in)

Height: 19.1 mm (0.752 in)

Length: 76.2 mm (3 in)

Industry: Medical, Industrial

Dimensions: 76.2 mm x 38.1 mm x 18.6 mm

Output Type: Negative

Unit Weight: 120 g

Output Power: 30 W

Input Voltage: 22 V to 30 V

Mounting Style: Through Hole

Isolation Voltage: 1.5 kVDC

Number of Outputs: 1 Output

Input Voltage - Max: 30 V

Input Voltage - Min: 22 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 30 mA

Output Voltage-Channel 1: 0 V to - 1 kV

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
