Wurth Elektronik 64900229522 Shrouded WR-MPC4 4.2mm ຜູ້ຊາຍ 2Pin Dual Agld

Pitch: 4.2 mm (0.165 in)

Application: Wire-to-Board

Unit Weight: 898 mg

Housing Color: White

Latching Type: Unlatched

Contact Gender: Pin (Male)

Current Rating: 9 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Number of Rows: 2 Row

Voltage Rating: 600 V

Contact Plating: Tin

Contact Material: Copper Alloy

Housing Material: Nylon

Termination Style: Solder Pin

Flammability Rating: UL 94 V-0

Number of Positions: 2 Position

Insulation Resistance: 1 GOhms

Termination Post Length: 3.6 mm (0.142 in)

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
