Wurth Elektronik 620303124022 Shrouded WR-WTB 2mm MaleSMT 3Pin Vtcl Shrouded

Pitch: 2 mm (0.079 in)

Application: Wire-to-Board

Unit Weight: 308 mg

Housing Color: Beige

Latching Type: Unlatched

Contact Gender: Pin (Male)

Current Rating: 2 A

Mounting Angle: Straight

Mounting Style: SMD/SMT

Number of Rows: 1 Row

Voltage Rating: 125 V

Contact Plating: Tin

Contact Material: Copper Alloy

Housing Material: Nylon

Termination Style: Solder

Mating Post Length: 3.5 mm (0.138 in)

Flammability Rating: UL 94 V-0

Number of Positions: 3 Position

Insulation Resistance: 1 GOhms

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 25 C
