- Accuracy
+ Cx:±（reading×1%+1pF）
+ tgδ: ±（reading×1%+0.00040）
- Anti-interference
- Capacitance range
+ Internal HV: 3pF～60000pF/10kV; 60pF～1μF/0.5kV
+ External HV: 3pF～1.5μF/10kV; 60pF～30μF/0.5kV
+ Resolution: Maximum 0.001pF, 4 valid figures.
- tgδ range:unlimited, 0.001% resolution, automatic identification for capacitance, inductance and resistance of three tested articles.
- Test current range
+ 10μA～1A
+ Power: 2kVA
- Internal HV
+ Voltage range: 0.5～10kV
+ Max output current: 200mA
+ Step-up and step-down voltage mode: Continuous smooth adjustment
+ Test Frequency: 45, 50, 55, 60, 65Hz single-frequency
45/55Hz, 55/65Hz, 47.5/52.5Hz automatic dual variable-frequency
+ Frequency Accuracy: ±0.01Hz
- External HV
+ When forward wiring the max test current is 1A, power frequency or variable frequency is 40-70Hz
+ When reverse wiring the max test current is 10kV/1A, power frequency or variable frequency is 40-70Hz
- CVT self-excited method low voltage output: Output voltage 3 ~ 50V, output current 3 ~ 30A
- Measuring time: About 40 s, correlate with the measurement mode
- Input Power: 180V～270VAC，50Hz±1%
- Computer Interface: Standard RS232 interface
- Printer: A7 thermal mini printer
- Temperature: -10℃～50℃
- Relative Humidity: <90%
- Dimension: 460×360×350mm3
- Weight: 28kg
Accessories
- Host
- CVT Wire
- LV Cable
- HV Cable
- Power Cord
- Ground Wire
- Thermal Paper
- Fuse
- Manual, Report, Certificate
