Scan mode
- Linear scan distribution:
Scan measurement range: (1kHz)-(2MHz), 2000 scan frequency point, resolution:1kHz
- Sectional scan measurement distribution:
Scan measurement range
+ (0.5kHz)～(1MHz), 2000 scan frequency point
+ (0.5kHz)～(10kHz)
+ (10kHz)～(100kHz)
+ (100kHz)～(500kHz)
+ (500kHz)～(1000kHz
Amplitude measurement range: (-100dB)～(+20dB)
Amplitude measurement accuracy: 0.1dB
Scan frequency accuracy: <0.01%
Signal input impedance: 1MΩ
Signal output impedance: 50Ω
Co-phase repetitive rate: 99.5%
Instrument dimension: 300×340×120mm3
Case dimension: 310×400×330mm3
Weight: 10kg
Accessories
- Host
- Case
- USB Cable
- Test clip
- Test Cable
- Bluetooth
- Power Cord
- Ground wire
- Manual, Report, Certificate
