Rated capacity: 800kVA
Working power supply: Three-phase 380V, power frequency 50Hz
Maximum rated AC voltage: 50kV
Maximum rated AC current: 16A
Output frequency: 50Hz
Device output waveform: Sine wave
Waveform distortion rate: ≤1.0%
Allowable continuous working time: 5 minutes at one time under rated conditions
Temperature rise: Temperature rise ≤50K after continuous operation under rated load for 5 min
Quality factor of this device: Q≥20 (f=50Hz)
Protection functions: Over-voltage, over-current, flashover and other protection functions
System measuring accuracy: Effective value of the system is 1.0
Noise level: ≤65dB
Product characteristics:
1. The required power capacity is greatly reduced, which is only 1/Q of the test capacity.
2. The weight and size of the device is greatly reduced to 1/10-1/30 of the taditional test device.
3. Obtaining a good sinusoidal waveform by reducing the waveform distortion of output voltage.
4. Efficiently finding the insulation weakness and preventing large short-circuit current from burning the fault point.
5. No recovery overvoltage.
6. Three working modes (automatic mode, manual mode, automatic tuning & manual boost mode) available for users to choose from.
7. Digital data can be stored and printed off-site.
8. Automatical frequency scanning with the result intuitively displayed on the LCD screen.
9.The DSP platform technology is adopted to make the human machine exchange interface more humanized
