Items: 1,1.2/50µs 2,250/2500µs 3,2~5µs etc waveforms
Output Peak Value: 100~10000kV
T1 Wave Front Time: 1.2µs±30%
T2 Wave Tail Time: 50µs±20%
Reverse Overshoot: <20%
Voltage Polarity: Positive/negative(manual shifting)
Waveform Shift: Auto shifting
Charging Time: 10s~999s, set arbitrarily
Instability of charging voltage: <1%
External Input: 50Hz/60Hz
Trigger Method: Auto or manual, can single trigger
Trigger Maloperation rate: <1%
Trigger Range: 100% rated charging voltage
Display Screen: 17-inch TFT color screen
Measurement Display Precision: Better than 3%
Tested Product Residual Voltage: <5kV
Voltage Measurement: Use damped impulse divider
Oscilloscope: TBS series, optional
Insulation Strength: ≤500V RMS (common to ground refer PE)
General Parameters
Power Source: AC220V±10%, 50/60Hz
Environment Temperature: -10±40ºC
Relative Humidity: 35%-85% RH (no condensation)
Ground Resistance: ≤0.5Ω
Structure Type: Open structure, independent control cabinet and main body, optical fiber connection
Control Console: 1.8M(length)*1.2M(height)*1M(width)
No conductive dust, no fire and explosion hazards, no corrosive metal and insulation gas, waveform of power voltage is sine wave, distortion <5%
Datasheet
Equipment model selection parameters | ||||||||||
Nominal Total Voltage kV | Class | Impulse Capacitance (μF) | Impulse Level Capacitance(μF) | Total Charging Power(kJ) | Application | |||||
±300~±900 | 3~9 | 0.133~0.111 | 0.4~1 | 6~45 | 35~110kV | |||||
±1000~±1600 | 10~16 | 0.05~0.0937 | 0.5~1.5 | 25~120 | <220kV | |||||
±1800~±2400 | 9~12 | 0.056~0.0833 | 0.5~1 | 90~240 | 220kV~500kV | |||||
±2800~±3200 | 14~16 | 0.0357~0.0625 | 0.5~1.5 | 140~320 | ||||||
±3600~±4800 | 18~24 | 0.0278~0.03125 | 0.5~2 | 80~240 | ||||||
Minimum time difference between pulse | 30s | 40s | ||||||||
Generator capacity per level | ≤1600kV use 100kV single side charging 1 | ≥1600kV use 100kV double sides charging | ||||||||
