DC voltage measurement
Rated total voltages:
10-30V; 50A
30V-60V; 150A
60V-150V; 100A
150V-300V; 50A
300V-450V; 50A
Discharge voltage ranges: DC 10V-450V
Accuracy & resolution: ±0.3% FS +0.3V; 0.1 V
DC voltage measurement
Internal current range: Max.150A at 1-150A adjustable
Accuracy & resolution: ±0.5% FS +0.6A; 0.1 A
Cell voltage type: 1.2V/2V/4V/6V/12V
Accuracy & resolution : ≤ ± 0.5%; 0.01 V
Power supply
Power supply: AC 110/220V (-20% to +20%), 50Hz/60Hz
Cooling mode: Forced air cooling
Communication & storage
Storage mode: USB Internal storage
Internal memory: 16MB flash or optional
Display: 7inch touch screen
High-voltage insulation test:
Input-The enclosure: 2200Vdc 1min
Input-Output: 2200Vdc 1min
Output- The enclosure: 700Vdc 1min
Safety standard: EN610950
Environment
Work temperature: -5～50℃
Storage temperature: -40～70℃
Humidity : 5%～95% RH
Altitude: Below 4000 m
Working noise : <60dB
Dimensions of host machine: 355x230x440mm
Dimensions of package: 480x250x410mm
Net weight: <50kg
