AC Input: 380V±15% 3-phase 3-wire +ground，50Hz±5Hz; THDi≤3%, PF>0.99
Output Voltage: Charging/Discharging 24V~1000V （Note：Customizable 48V~1500V）
Output current (charge and discharge): -1000A~+1000A
Single channel output power: 500kW
Voltage Accuracy: ±0.05%FS
Current Accuracy: ±0.05%FS
Sampling Resolution: AD：16bit
Input Resistance: ≥1MΩ
Whole Efficiency: >93%
Work-step Time Range: ≤(365*24)hours/Working step
Charge/discharge Response Time (10%~90%): ≤10ms
Charge/discharge Conversion Time (-90%~90%): ≤20ms
Charging
Charging Mode: CC charging, CV charging, CP charging, CC and CV charging
Cut-off Conditions: Voltage, Current, Time, Capacity
Discharging
Discharging Mode: CC discharging, CP discharging, CR discharging, CV discharging
Cut-off Conditions: Voltage, Current, Time, Capacity
Loop
Loop Test Range: 1~65535 times
Number of steps in single loop: 254 steps
Nested Loop: With nested loop function, it supports up to 3 levels of nesting
Others: Other Functions: Internal resistance test, capacity test, working condition simulation test, offline test support
Protection
Software Protection:
Self-test protection (contactor failure, transformer over-temperature, A/D channel damage, IGBT damage, etc.)
Safety protection conditions can be set such as software over-voltage protection, software under voltage protection, software over-current protection, software under-current protection, auxiliary temperature protection, auxiliary voltage protection. Meanwhile, the voltage and current values are protected to be set, and displayed in the list of tips and records after the channel protection.
Hardware Protection: Emergency stop protection, anti-reverse connection protection, short circuit protection, offline protection, power-down data protection
Protection Class: IP21
Cooling Method: Forced air cooling
Channel Control Mode: Independent control, channels can be connected in parallel
Noise: <75dB
Databases: Centralized management of test data using MySQL database
Upper Computer Communication Mode: Based on TCP/IP protocol
Data Output Method: EXCEL、TXT、Diagrams
Human-computer Interaction: Touch color screen/PC
Communications Interface: RS485/LAN/CAN-10℃~45℃
Operating Temperature: -10℃~45℃
Humidity: ＜90%（non-condensing）
