WMT CNC ZAY7032FG ເຄື່ອງເຈາະແລະເຄື່ອງເຈາະ (1.5KW)

Drilling capacity: Φ32mm

Max. boring diameter: Φ50mm

Face milling capacity: Φ63mm

End milling capacity: Φ20mm

Distance from spindle nose to table: 450mm

Min.distance from spindle axis to column: 260mm

Spindle travel: 130mm

Spindle taper: MT3, MT4 or R8

Step of spindle speed: 6 steps

Range of spindle speed 50Hz: 80-1250 rpm

60Hz: 95-1500 rpm

Swivel angle of headstock (vertical): ±90°

Table size: 800x240mm (Optional 900×240mm )

Forward and backward travel of table: 175mm

Left and right travel of table: 500mm

Motor power: 1.5KW (2HP)

Net weight/gross weight: 320/370kg

Packing size: 770×880×1160mm
