Max.Swing.over bed: Φ330mm(13″)
Max.Swing.over cross slide: Φ185mm(7-7/25″)
Max.Swing.over gap: Φ480mm(19″)
Bed width: 260mm(10″)
Distance between centers: 1000mm(40″)
Taper of spindle bore: MT5
spindle bore: Φ40(1-1/2″)
Steps of spindle speeds: 12steps
Range of spindle speeds: 40-1800rpm
Spindle nose: D-4
Metric thread range: 0.45~7.5mm(22kinds)
Inch screw thread range: 4~112TPI(40kinds)
Range of longitudinal feeds: 0.03-0.688mm(0.0011-0.0271″in/rev)
Range of cross feeds: 0.015-0.220mm(0.0003″-0.01″in/rev)
Diameter of leadscrew: Φ22mm(7/8″)
Pitch thread of leadscrew: 4mm(8T.P.I)
Travel of tailstock quill: 120mm(4-3/4″)
Diameter of tailstock quill: 45mm(1-25/32″)
Taper of tailstock quill: MT3
Main motor power: 1.5/2.4(3HP)
Coolant pump motor power: 0.04(0.055HP)
Packing size: 1900×760×1460mm
N.W/G.W: 960/1090kg
