Operating pressure:
High-pressure connection¹: 5 – 320 bar
With pump operation: 0 bar
Viscosity range fluid: 5 – 1000 mm²/s
Operating temperature range fluid²: 0 – +60°C
Operating conditions:
Temperature: -10 – +60°C
Relative humidity: 0 – 95% r.H. (non-condensing)
Power supply device:
Power supply: 24 VDC
Power consumption: max. 8A
Power supply for the according power adaptor
Power supply: 100 – 240 VAC (50/60 Hz)
Power consumption: max. 4A
Power at 24VDC-output: max. 221W
Measuring range oil parameter
Relative permittivity: 1 – 7
Relative humidity: 0 – 100%
Conductivity: 100 – 800000 pS/m
Temperature: -20 – +120°C
Measuring accuracy
Particle measurement (within the calibration range) - ISO4 / ISO6: ±1 ordinal number (OZ)
Particle measurement (within the calibration range) - ISO14 / ISO21: ±2 ordinal number (OZ)
Relative dielectric number³: ±0.015
Relative humidity (10 – 90%)⁴: ±3% r.H.
Relative humidity (<10%, >90%)⁴: ±5% r.H.
Conductivity (100 – 2000 pS/m): ±200 pS/m
Conductivity (2000 – 800000 pS/m): typ. <10%; Temperature: ±2K
Interfaces: USB-B, SD-card (SD or SD-HC in FAT/FAT16/FAT32-data format)
Size internal data memory: 1250 readings (with time stamp)
Weight: <10 kg
¹ Depending on the oil viscosity
² Viscosity of the fluid must be within the permissible range
³ Calibrated to n-Pentane at 25°C
⁴ Calibrated to air at room temperature
