Measuring accuracy:
± 2.5% of full-scale in the centre third of the measuring range
± 4% of full-scale in upper & lower thirds
Repeatability: ± 1% of full scale
Flow measuring range: 1.5 - 1300 SCFM (Standard cubic feet per minute)
Max. operating pressure: Aluminium & brass 40 bar (580 psi), stainless steel 70 bar (1,000 psi)
Max. operating temperature: 115° C (240° F)
Pressure differential: See graphs below
Calibration: Air @ 21°C, 1.0 sg and 6.9 bar (100 psi)
Flow calibration certifcates are available on request, this is a chargeable option.
Note: Must be requested at time of order & cannot be retrospectively requested
