Digital:
Processor: DSP Texas TMS320C6713B
Memory:
Storage: Micro SD card 4 GB
RAM: 128 MB
Flash Memory: 2 × 16 MB
ADC:
Resolution: 16-bit
Maximum Synchronous Sampling Rate: 192 KSPS
Display:
Size & Resolution: 5” Amorphous-TFT-LCD, 480 × 272 pixels
Input/Output Signals:
AC Input: Compatible with all standard ICP accelerometers (4mA/24V), velocimeters, or general-purpose AC sensors within the range of 0–30 V RMS (Default VMI sensors are automatically detected).
DC Input: 0–5 V
External Reference: 0.8–24 V
Built-in Sensors:
Temperature: -20 to 120 °C (Infrared)
Measurement:
Signal Processing: Direct, single or double integration, or differentiation (set up via software based on the selected sensor and user preferences). Capable of simultaneous 3-channel sampling.
Frequency Range: 0.5 to 32,000 Hz (Dependent on the sensor).
Amplitude Range: 0 to 80 g (Dependent on the sensor).
Accuracy:
0.01 g ± 1% without integration
0.1 mm/s ± 2% for single integration
2 µm ± 3% for double integration
FFT Lines: 25,600
Sampling Rate: Up to 131,072 Hz, depending on the selected frequency range (Simultaneous 3-channel sampling).
Power:
Battery: Smart Li-ion battery, 6.2 Ah with a fuel gauge
Usage Time: 12 hours (under normal operating conditions)
Charging Time: 4 hours (under normal charging conditions)
Temperature:
Operating: -20 °C to +70 °C (-4 °F to 158 °F)
Storage: -30 °C to +80 °C (-22 °F to 176 °F)
