Single Channel advanced
Accuracy specifications valid for one year for ambient temperatures within 5 °C of calibration temperature.
Voltage Range (Measureable): 2000V (850Vrms) max. continuous
Internal Current Range (Measurable): 150Apk (30Arms) max. continuous
External Current Transducers (Measurable): 35Vpk (15Vrms) max. continuous
Voltage & Current Accuracy: See charts below
Frequency Measurement Accuracy: 0.005%
Crest Factor Accuracy: V: (50mV + 0.01% of pk rng)/RMS value A: 50uA + 0.01% of pk rng)/RMS value
Harmonic Accuracy (Voltage & Current): 0.02%
Waveforms: Actual, Peak Capture, Distortion and Glitch Capture
Charts, with Zoom & Scroll: History, Startup and Inrush
Line Switch
Max Open Voltage: 720Vpk (480Vrms)
Max Surge Current: TBD
Max On Current: 10Arms
Turn On Phase: 1° resolution
Digital Interfaces: GPIB (IEEE-488), USB (host and device), RS-232, Digital IO
Physical
Power Input: 12VDC @ 1.5A minimum output
Size: (HxWxD) 4.7″ x 13.8″ x 9.5″ (11.94cm x 35.05cm x 24.13cm)
Weight: 7.5 lbs
Operating Range: 0°C to 55°C, less than 95% R.H. (non-condensing)
Storage Range: -20°C to 670°C, less than 95% R.H. (non-condensing)
Unit is supplied with one Vitrek T5 universal external power supply, 100-240Vrms, 50-60Hz, with a 2.5mm 12VDC output plug and a three-prong IEC320 AC inlet receptacle, plus a three-prong AC power cord.
