Voltage: Range: 950Vpk, 400Vpk, 1500Vpk (see ordering information)
Internal Current: Range: 8Apk, 40Apk (see ordering information)
External Current Transducers (Option E only):
Current: 10Arms for 50ms, 2.5Arms continuous, 5Apk measurable
Scaling (In=Out) = +0000.00A = 00.0000A through +-9999.99A = 9999.99A
Voltage: 25Vpk for 50ms, 2.5Vrms continuous, 2.5Vpk measurable
Scaling (In=Out) = +0000.00V = 00.0000V through +-9999.99V = 9999.99V
RESOLUTION: 0.05% of range
VOLTAGE & CURRENT ACCURACY: (See chart to left)
FREQUENCY MEASUREMENT: 20 mHz to 80 kHz, 0.01%
CREST FACTOR: Range: 1 to 99, Accuracy: from peak results
HARMONIC AND SPECTRUM ANALYSIS:
FREQUENCY RANGE: 20 mHz to 50 kHz
Typical accuracy at line frequencies of 50/60 Hz:
THD: 0.1%
Harmonic: 0.05%
Phase: 0.1°
WAVEFORMS: Actual, Peak Capture, and Distortion content
PHYSICAL:
POWER INPUT: 80-265 Vrms autoselect, 40 - 400 Hz @ 25 VA max
SIZE: (HxWxD) 4-1/2” x11-1/2” x10-1/2”
WEIGHT: 8 lbs
OPERATING RANGE: 0°C to 45°C, <85% RH @ 40°C non-condensing
STORAGE RANGE: -30°C to 65°C <95% RH @ 40°C non-condensing
Digital interfaces (standard): IEEE488.1: Full talk/listen capabilities
Parallel: IEEE1284, unformatted text or PCL compatible
