Fall Time: 31 ns
Rise Time: 96 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: N-Channel E Series Power MOSFET
Qg - Gate Charge: 42 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 500 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 31 ns
Typical Turn-Off Delay Time: 37 ns
Id - Continuous Drain Current: 51 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 4.6 S
Rds On - Drain-Source Resistance: 84 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 5 V
