Width: 5.13 mm
Height: 1.04 mm
Length: 6.15 mm
Fall Time: 22 ns
Rise Time: 3 ns
Technology: Si
Unit Weight: 506.600 mg
Channel Mode: Enhancement
Configuration: Dual
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 25 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 48 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 21 ns
Id - Continuous Drain Current: 30 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 24 S
Rds On - Drain-Source Resistance: 17.9 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
