Fall Time: 5 ns
Rise Time: 5 ns
Technology: Si
Unit Weight: 57.220 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 600 pC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.25 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 5 ns
Typical Turn-Off Delay Time: 20 ns
Id - Continuous Drain Current: 500 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1.2 S
Rds On - Drain-Source Resistance: 1.46 Ohms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 400 mV
