Fall Time: 6 ns
Rise Time: 21 ns
Technology: Si
Unit Weight: 1 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 40 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 69.4 W
Vgs - Gate-Source Voltage: - 12 V, + 16 V
Typical Turn-On Delay Time: 12 ns
Typical Turn-Off Delay Time: 30 ns
Id - Continuous Drain Current: 108 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 115 S
Rds On - Drain-Source Resistance: 4 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 2.3 V
