Vishay BC Components D123M33Z5UH6TL2R ອຸປະກອນກະສົງດິດຊິດ DC ຊັ້ນດຽວຊະນິດເຊຣມິກ ລະດັບ 1, ລະດັບ 2, ລະດັບ 3 D 100V 12nF +/- 20% Z5U REEL e3

Class: Class 2

Diameter: 8.5 mm

Thickness: 3.5 mm

Tolerance: 20 %

Dielectric: Z5U

Lead Style: Straight

Application: General Purpose

Capacitance: 0.012 uF

Lead Spacing: 2.5 mm

Lead Diameter: 0.6 mm

Voltage Rating: 100 V

Capacitance - nF: 12 nF

Capacitance - pF: 12000 pF

Termination Style: Radial

Voltage Rating DC: 100 VDC

Operating Temperature Range: - 30 C to + 125 C

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 30 C

Temperature Coefficient / Code: - 56 %, + 22 %
