Receiver:
Sensor: CMOS (Mono, Global Shutter)
Resolution: 2560 × 2048
Focus: Mechanical Auto Focus
Maximum Frame Rate (FPS): 40
Focal Length:
Standard Range: 8 mm (0.3149”)
Pixel Size: 3.2 μm × 3.2 μm
Sensor Size: 1/1.7”
Emitter:
Illumination Light Source Option: High Intensity White LED
Lens Cap Option: Polarised
Reading Specifications:
Supported Symbols: 2D Codes: QR Code, Data Matrix, Micro QR and PDF417
Barcodes: Code 39, Code 93, Code 128, Codabar, EAN8, EAN13, ITF25, ITF14, MATRIX25, UPCA, UPCE, MSI, CODE11, INDUSTRIAL25, CHINAPOST and PHARMACODE
Minimum Resolution: 2D Codes: 0.030 mm (0.0011”), Barcodes: 0.010 mm (0.0003”)
Reading Distance:
Standard Range: 25 mm to 600 mm (0.9842” to 23.6220”)
Reading Field of View (Working distance at 300 mm (11.8110”)
Standard Range: 307.20 mm x 245.76 mm (12.0944” x 9.6755”)
Maximum Reading Speed: 90 codes / sec
I/O Specifications
Number of Control Inputs: 3
Number of Control Outputs: 3
Ethernet Supported Protocol: SmartSDK, TCP Client, Serial, FTP, TCP Server, ModBus and UDP
Serial Communication Standard: RS-232C Compliant
Environment Resistance
Enclosure Rating: IP67 *4
Surrounding Temperature: 0 to + 45 ° C (32 to 113 ° F)
Ambient Storage Temperature: -30 to + 70 ° C (-22 to 158 ° F)
Rating
Power Consumption: 24 W
Power Supply Voltage: 24 VDC
Current Consumption: 1 A
Weight: Approx. 540 g (1.1905 lb.)
Dimension (L x W x H): 78.20 mm x 63.65 mm x 125.25 mm (3.0787” x 2.5059“ x 4.9311”)
