Output Voltage (0–Umax): 0–160V
Output Current (0–Imax): 0–5A
Output Power (0–Pmax): 0–300W
Rated Operating Conditions:
Rated input voltage: AC 220 V ±10%, 50 Hz (optional AC 110 V ±10%, 60 Hz)
Operating temperature: 0–40°C
Operating relative humidity: ≤80% RH
Storage temperature: −20–60°C
Storage relative humidity: ≤80% RH
Calibration ambient temperature: 23°C ±5°C
Voltage:
Setting resolution: 100 mV
Setting accuracy: ≤0.1% + 5 digits
Readback resolution: 100 mV
Readback accuracy: ≤0.1% + 5 digits
Temperature coefficient: ≤0.02% + 3 mV
Ripple & noise: ≤12 mVrms
Current:
Setting resolution: <10A: 1 mA; ≥10A: 10 mA
Setting accuracy: ≤0.2% + 10 digits
Readback resolution: <10A: 1 mA; ≥10A: 10 mA
Readback accuracy: ≤0.2% + 10 digits
Temperature coefficient: ≤0.02% + 3 mA
Ripple & noise: ≤26 mArms
Load regulation: ≤0.2% Umax + 5 mV
OVP: 0–161 V
OCP: 0–5.5 A
Max output voltage: 160.5 V
Max output current: 5.1 A
Cooling method: Fan cooling
Weight: ≤2.2 kg
Dimensions (W × H × D): 80 × 150 × 230 mm
