Output Voltage (0–Umax): 0–100V
Output Current (0–Imax): 0–3A
Output Power (0–Pmax): 0–300W
Rated Operating Conditions
Operating voltage: AC 220 V ±10%, 50 Hz (optional AC 110 V ±10%, 60 Hz)
Operating temperature: 0–40°C Relative humidity: ≤80% RH
Storage temperature: −20–60°C Relative humidity: ≤80% RH
Calibration ambient temperature range: 23°C ±5°C
Setting resolution: <100V: 10mV; ≥100V: 0.1V
Setting accuracy: ≤0.1% + 5 digits
Readback resolution: <100V: 10mV; ≥100V: 0.1V
Readback accuracy: ≤0.1% + 5 digits
Temperature coefficient: ≤0.02% + 3mV
Ripple & noise: ≤18mVrms
Current :
Setting resolution : <10A: 1mA; ≥10A: 10mA
Setting accuracy : ≤0.2% + 10 digits
Readback resolution : <10A: 1mA; ≥10A: 10mA
Readback accuracy : ≤0.2% + 10 digits
Temperature coefficient : ≤0.02% + 3mA
Ripple & noise : ≤18mVrms
Protection / Output :
Load regulation : <10A: ≤0.1% Umax + 5mV; ≥10A: ≤0.2% Umax + 5mV
OVP : 0–103V
OCP : 0–3.5A
Max output voltage : 102V
Max output current : 3.1A
Cooling method : Fan cooling
Weight : Approx. 2.0 kg
Dimensions : 230 × 80 × 150 mm
