Function: Insulation resistance measurement (IR); polarization index measurement (PI); Dielectric absorption ratio (DAR); Step test (STEP); Ramp test(RAMP); Dielectric discharge index(DD); Voltage test(V); Capacity test(uF)
Power Supply: Rechargeable lithium battery 6.2Ah 14.8V
Output Voltage Gear: 50V, 250V, 500V, 1kV, 2.5kV, 5kV
Custom Setting Voltage: 40~5kV
Output Voltage Accuracy: (5%～10%)±10V
Insulation Resistance Test Range: 0..005MΩ～10.0TΩ
Output Short Circuit Current: ≥7mA
Polarization Index Test: Yes
Dielectric Absorption Ratio Test: Yes
Step Mode (STEP): Yes
Ramp mode(RAMP): Yes
Dielectric discharge index(DD): Yes
Voltage Test
Range: DC:0V~800V；Accuracy: ±5%rdg±3V
Range: AC: 0V~700V; Accuracy: ±5%rdg±3V
Capacitance Test: Range:10nF～200uF；Accuracy: ±10%rdg±10nF
Real Time Current Display: Display test current value, current display range: 0.001nA～7.5mA
Real Time Voltage Display: Real time monitoring the voltage of the tested terminal,In the non-test state, when the voltage is larger than 36V, the test is prohibited to protect the safety of the instrument and the operator.
Test Timer: Automatic record test time, time range: 0s~9999s
Test Time: After selecting the DAR, PI, DD test options, the test will be stopped immediately after the test result is obtained; in the custom test mode, the test duration can be set by user; in the normal test mode, the test time is not limited, and the operator can manually stop the test.
Custom Setting Time: 10s~3600s
Store Function: Automatically store the test data, which can reply the test record in tester
USB Communication: Yes, the test record can upload to the PC through USB cable
Bluetooth Communication: Yes, can be connected to Android phones or other devices with Bluetooth communication function.
Battery Power Display: With battery power display, when battery voltage low will remind to charge in time
Automatic Shutdown: After 15 minutes start up will shut down automatically without any operation
Tester Dimension: 280mm×260mm×160mm
Tester Weight: Host: 4326g (include the battery); Total weight: 6.96kg (Accessories)
Protection Level: Close the case IP65, open the case IP40
Working Environment: -20℃～50℃；80%rh
Store Environment: -25℃～65℃；80%rh
Insulation Resistance: 50MΩ(1000v)(between the test circuit and shell)
Withstand Voltage: AC 3kV 50Hz 1min(between the test circuit and shell)
Suitable Safety Standard: IEC61010-1,IEC61326-1
