VICTOR 88D Digital Multimeter (1000VDC, 750VAC, 20ADC/AC, True RMS)

DC Voltage:200mV/2V/20V/200V/1000V±(0.1%+5)

AC Voltage:2V/20V/200V/750V±(0.8%+25)

DC Current:200uA/2mA/20mA/200mA /20A±(0.8%+5)

AC Current:2mA/20mA/200mA /20A±(1.5%+25)

Resistance:200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20 MΩ/200MΩ±(0.5%+8)

Capacitance:20nF/200nF/2uF/20uF/200uF/2000uF±(4.0%+10)

Frequency:10Hz/100Hz/1kHz/10kHz/100kHz/1MHz±(3.0%+150)

Celsius:

(-20 ~ 1000)℃ (0-1832)℉ <400℃±(1.0%+40) / ≥400℃±(1.5%+150)

Special Function

Diode test√

Continuity buzzer√

Low battery indication√

Backlight√

Auto power off√

Function protection√

Restorable Fuse protection√

Shock proof protection√

Input impedance:10MΩ

Sampling rate:3 times/s

AC frequency response:(40-400)Hz

Operation way:Manual range

Max. Display:19999

LCD size:65×45mm

Battery:9V (6F22)

General Characters

Product Net WeightApprox. : 400g(including battery )

Product Dimension189×97×35mm

Standard AccessoriesTest leads / battery /instruction manual/TPO1 temperature probe/Testing accessories
