Mechanical Data:
Dimension: 130 × 130 × 390 mm (5.12 × 5.12 × 15.35 in)
Weight: 0.6 kg (21.16 oz)
Connector Type: N plug (male)
Environmental Data:
Operating Temperature: –20 to +55 °C
Electrical Data:
Frequency Range: 400 to 6000 MHz (usable down to 30 MHz)
Linear Dynamic Range: 0.2 mV/m to 200 V/m (1 dB compression point)
Sensitivity: < 0.3 mV/m
Maximum Field Strength (destruction limit): 300 V/m
Isotropy: ±1.5 dB (400–1500 MHz) / ±2.0 dB (1500–2000 MHz) / ±2.5 dB (2000–3500 MHz) / ±3.5 dB (3500–6000 MHz)
Impedance: 50 Ω
Control and Power Supply: USB
Included Accessories:
• SDSW-03 USB remote axis selector
• 1.5 m ferritized composite cable with calibration certificate
• Vertical support for ¼" thread mount
• Calibration certificate with antenna factor and return loss data
• Hard carrying case
