General Specifications
Display Type: 5 digit VFD
Overload Indication: Flashes OVERLOAD
Conversion Rate: 45 readings per second
Terminal Configuration: 4-Wire Kelvin
Max Kick-Back Protection: 500A Peak Induced Current
Compl. Voltage (Normal Mode): 7.5 VDC Nominal @ 10A resistive
Compl. Voltage (Charging Inductor Mode): 20 VDC when indicator is on
Test Current Polarity: Positive (flows High to Low)
Open Circuit Voltage (Test Current Off): <20mV
Power Requirements: 115VAC or 230VAC ±10%
Temperature
Operating Temp. Range: 0°C~50°C
Storage Temp. Range: -40°C~85°C
Humidity: 80% RH max @ 40°C (non-condensing)
Physical Specifications
Width|Depth|Height: 17”/43cm|11.5”/29.5cm|4”/10cm
Weight: 20lbs/9kg net
Accessories:
Omni Compensator (Temperature Sensor)
19” Rack Mount Adaptor
Remote Foot Switch for Test Current
Options:
USB Interface
Binary Coded Decimal Interface
GPIB Interface
Rear Locking Connectors
