- Reporting range: 1 m … 100 km (3 ft … 62 mi)
- Reporting resolution: 1 m (3 ft)
- Reporting uncertainty in operational conditions:
±10 % or ±1 m at 1 m … 10 km (±3 ft at 3 ft … 6.2 mi) 1)
±20 % at 10 … 100 km (6.2 … 62 mi)
- Measurement error: ±0.7 %
- Operating principle: Look-down forward scatter
- Scattering angle (main receiver): 42° ±0.25°
Scattering angle (side receiver): 90° ±0.25°
- Light source: Near-infrared
- Sampling frequency: 5 MHz
- Measurement cycle: 5 s
- Operating voltage:
Measurement unit with interface unit: 115/230 V AC ±10 %, 50 … 60 Hz
Measurement unit only: 10 … 50 V DC
- Heating voltage: 24 V AC or V DC ±10 %
- Dimensions, measurement unit: 354 × 551 × 883 mm (13.94 × 21.69 × 34.76 in)
- Weight, measurement unit: Max. 7.5 kg (16.5 lb)
- IP rating: IP66
